PR-03Part report · Turned bushing
Turned bushing
100 bushings, brass CW614N, Ø30 × 80 mm
1.0The request
A purchasing team in Helmond moved 100 turned bushings from a platform order: Ø30 × 80 mm in brass CW614N, with ±0.05 mm requested.
“Quote 100 CW614N bushings, Ø30 × 80 mm, requested dimensional tolerance ±0.05 mm.”
- Left open
- Turning fitted the size, but brass always needs an application and compliance discussion.
- Agreed before quoting
- Bore, fit, end use and lead restrictions, finish, inspection and date.
2.0How the review settled it
- 1Material first
Brass always gets an application and compliance review, so Milan asked for the intended use and any evidence the product needs.
- 2The diameter that matters
Bas asked which diameter carried the fit. Only the bore and one outer diameter needed ±0.05 mm.
- 3Report scope
The dimensional report covered those two features, measured on the first part and a sample from the batch.
- 4Quotation
With the material question settled, the quotation named the stock, the report scope and the date.
Turning fitted the size, and the material review came first. The bushings shipped with a report on exactly the features the buyer needed.
3.0Specification and screen
SpecificationBrass CW614N · Round Ø30 × 80 mm · ±0.05 mm · 100 parts · As machined
- Outside3-axis millingMilling screens block shapes only.
- Outside5-axis millingMilling screens block shapes only.
- ReviewCNC turningBrass needs an application and compliance review.
Data revision 2026-10-12-demo-2. Geometry and drawing review still required.
Use this example in the check4.0What the buyer said
★★★★★
Our turned spacers moved here from a platform order. Same drawing, but Bas asked which diameter actually mattered, and the report covered exactly those features.
Reviews on this demo are written by Vulpesco.
5.0Questions
Why did turning need review?
Brass CW614N always adds an application and compliance review, even when size and tolerance fit.
Do you certify lead content?
No. Tell us the evidence your product needs; we confirm what the stock documents cover before quoting.
Can the bushings get a finish?
Plating is listed for metals for discussion only. Name the specification and we review it with the quotation.
6.0Related
7.0Next step
A part with related faces or a few tight features? Send what you know; the review settles the rest before anyone quotes.
